AudioCodes Mediant 1000 Hardware Installation Manual

CHAPTER3 Physical Description
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
Figure 3-9: Fan Tray Module
For replacing the Fan Tray module, see Replacing the Fan Tray Module.
Power Supply Module and LED Description
The device can house up to two extractable power supply modules (Power 1 and Power 2),
each providing an AC power connector on the device's rear panel. The dual power option
provides the device with load sharing and power redundancy in case of failure in one of the
power sources or modules. When using this feature, you are advised to connect each power
supply unit to a different AC supply circuit.
Figure 3-10: Power Supply Module
Table 3-11: Power Supply Module LED Description
LED Color State Description
POWER Green On Power supply is operating correctly.
- Off Failure / disruption in the AC supply, or the power is
currently not being supplied to the device through the
AC power supply entry.
- 16 -

AudioCodes Mediant 1000 Specifications

General

Data link protocols	CAS: MF-R1: T1 CAS, ISDN PRI: ETSI/EURO ISDN, ANSI NI2, QSIG
Security algorithms	HTTPS, SRTP
Authentication method	RADIUS
Internal memory	512 MB
Built-in processor	Celeron 600 MHz
Processor frequency	600 MHz
Internal memory type	-
Number of processors installed	1
Voice codecs	G.711, G.723.1, G.726, G.729A, iLBC
Safety	UL60950-1, FCC 47 CFR
Certification	ETS 300019-2-1, ETS 300019-2-2 ETS 300019-2-3
Mounting type	Rack mounting
LED indicators	Yes
Power requirements	90-260 V AC

Weight and Dimensions

Size (imperial)	19 \
