CHAPTER1 Introduction
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
1 Introduction
This document provides a hardware description of the Mediant 1000B Gateway & E- SBC
(hereafter referred to as device) and step-by-step procedures for cabling the device.
The device is a 19-inch industrial platform chassis, 1U high and 13.8 inch deep. The chassis'
modular hardware design allows scalability to capacity demands and optional telephony
interfaces to suite your requirements.
The device supports the following interfaces:
■ Analog and Digital Telephony (Separate orderable item):
● Up to four digital trunks modules, supporting up to 6 x E1 / 8 x T1 (1, 2, or 4 E1/T1/J1
PRI spans per module)
● Up to five BRI modules, where each module provides four BRI ports
● Up to six FXO modules, where each module provides four FXO ports
● Up to six FXS modules, where each module provides four FXS ports
■ (Separate orderable item) Up to four Media Processing modules (MPM), providing
additional DSP resources for SBC transcoding and/or three-way conferencing
■ Up to seven LAN Ethernet interfaces:
● Three interfaces on the CRMX module
● (Separate orderable item) Four interfaces provided by a LAN Expansion module (SWX)
■ (Separate orderable item) Open Solution Network (OSN) server modules for hosting third-
party applications (such as an IP PBX)
■ Dry-contact alarm relays for connection to an external audible or visual alarm system (e.g.,
bell)
■ Fan Tray module
■ Up to two Power Supply modules
● Hardware configurations may change without notice. Currently available
hardware configurations are listed in AudioCodes Price Book. For further
enquiries, please contact your AudioCodes sales representative.
● For information on configuring the device, refer to the device's User’s Manual.
