AudioCodes Mediant 1000 Hardware Installation Manual

CHAPTER5 Cabling the Device
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
Table 5-3: Micro-HDMI Type-D Connector Pinouts
Pin Signal
3 TMDS Data2+
4 TMDS Data2 Shield
5 TMDS Data2-
6 TMDS Data1+
7 TMDS Data1 Shield
8 TMDS Data1-
9 TMDS Data0+
10 TMDS Data0 Shield
11 TMDS Data0-
12 TMDS Clock+
13 TMDS Clock Shield
14 TMDS Clock-
15 CEC
2 Utility/HEAC+
17 SCL
18 SDA
16 DDC/CEC/HEAC Ground
19 +5 V Power
1 Hot Plug Detect/HEAC
Connecting to Power
The procedure below describes how to connect the device to the AC power supply. You can
install up to two Power Supply modules (Power 1 and Power 2) for power redundancy. For
installing the Power Supply modules in the chassis, see Power Supply Module.
- 54 -

AudioCodes Mediant 1000 Specifications

General

Data link protocols	CAS: MF-R1: T1 CAS, ISDN PRI: ETSI/EURO ISDN, ANSI NI2, QSIG
Security algorithms	HTTPS, SRTP
Authentication method	RADIUS
Internal memory	512 MB
Built-in processor	Celeron 600 MHz
Processor frequency	600 MHz
Internal memory type	-
Number of processors installed	1
Voice codecs	G.711, G.723.1, G.726, G.729A, iLBC
Safety	UL60950-1, FCC 47 CFR
Certification	ETS 300019-2-1, ETS 300019-2-2 ETS 300019-2-3
Mounting type	Rack mounting
LED indicators	Yes
Power requirements	90-260 V AC

Weight and Dimensions

Size (imperial)	19 \
