CHAPTER6 Hardware Maintenance
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
a. Remove the blank-panel slot cover from the slot intended for the HDMX module, by
gently pulling on the handle of the module until it slides out of the slot.
b. Hold the HDMX module in the correct orientation, as shown in the following figure,
and gently insert the module into the slot, sliding it along the slot's guide rails until it
makes contact with the card-edge connector located on the backplane.
Figure 6-12: Inserting HDMX Module into Slot
c. Push the module's handle until it clicks firmly into the slot.
3. Install the OSN Module:
a. Remove the blank-panel slot cover from the slot intended for the OSN module, by
gently pulling on the handle of the module until it slides out of the slot.
b. Hold the OSN module in the correct orientation, as shown in the following figure, and
gently insert the module into the slot, sliding it along the slot's guide rails until it makes
contact with the card-edge connector located on the backplane.
Figure 6-13: Inserting OSN Module into Slot
- 65 -
