9. Commissioning (basic settings)
1. Set selector switch to position 0 (OFF).
Information: The selector switch is not a mains switch.When positioned to 0
(OFF), the actuator cannot be operated.The controls' power supply is
maintained.
2. Switch on the power supply.
Information:Please consider the heat-up time for ambient temperatures below
20 °C.
3. Perform basic settings.
9.1 Type of seating: set
Valve damage due to incorrect setting!
The type of seating must suit the valve.
Only change the setting with prior consent of the valve manufacturer.
Customer settings M0041
Type of seating M0012
End position CLOSED M0086
End position OPEN M0087
Default value: Limit
Setting values:
Limit
Seating in end positions via limit switching.
Torque
Seating in end positions via torque switching.
Select main menu
1. Set selector switch to position 0 (OFF).
2.
Press push button C Setup and hold it down for approx. 3 seconds.
Display goes to main menu and indicates: Display...
Select parameter
3. Select parameter either:
click via the menu to parameter, or
via direct display: press and enter ID M0086 or M0087
Display indicates: End position CLOSED
CLOSE or OPEN
4.
Use Up Down to select:
End position CLOSED
End position OPEN
The black triangle indicates the current selection.
5.
Press Ok.
Display indicates the current setting: Limit or Torque
The bottom row of the display indicates either:
-
Edit continue with step 6
-
Save continue with step 10
41
