12.3 Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
Standard: IP 68 with AUMA 3-ph AC motor/1-ph AC motor
According to AUMA definition, enclosure protection IP 68 meets the following requirements:
Depth of water: maximum 8 m head of water
Duration of continuous immersion in water: max. 96 hours
Up to 10 operations during flooding.
Modulating duty is not possible during continuous immersion.
For actual version, refer to actuator/controls name plate.
Enclosure protection according
to EN 60529
Standard:
KS: Suitable for installation in industrial units, in water or power plants with a low pollutant
concentration as well as for installation in occasionally or permanently aggressive atmo-
sphere with a moderate pollutant concentration (e.g. in wastewater treatment plants,
chemical industry)
Options:
KX: Suitable for installation in extremely aggressive atmospheres with high humidity and
high pollutant concentration
Corrosion protection
Standard: 2,000 m above sea level
Option: > 2,000 m above sea level, please contact AUMA
Installation altitude
Up to 100 % relative humidity over the entire permissible temperature rangeHumidity
Pollution degree 4 (when closed) according to 50178Pollution degree
Standard: Paint based on polyurethane (powder coating)Finish coating
Standard: AUMA silver-grey (similar to RAL 7037)Colour
Standard:
Open-close duty: 25 °C to +70 °C
Modulating duty: 25 °C to +60 °C
For actual version, refer to actuator/controls name plate.
Ambient temperature
1 g, from 10 to 200 Hz
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength
may not be derived from this. Not valid in combination with gearboxes.
Vibration resistance according
to IEC 60068-2-6
AUMA part-turn actuators meet or exceed the lifetime requirements of EN 15714-2. For further
details, please contact AUMA
Lifetime
Refer to separate technical dataWeight
12.4 Accessories
AUMATIC mounted separately from the actuator, including plug/socket connector. Connecting
cables on request. Recommended for high ambient temperatures, difficult access, or in case
of heavy vibration during service
Wall bracket
1)
AUMA ToolSuiteProgramming software for PC
Cable length between actuator and AUMATIC max. 100 m. Not suitable for version with potentiometer in the actuator. Instead of the
potentiometer, an RWG has to be used.
1)
12.5 Further information
Electromagnetic Compatibility (EMC): (2004/108/EC)
Low Voltage Directive: (2006/95/EC)
Machinery Directive: (2006/42/EC)
EU Directives
65
SA 07.2 SA 16.2/SAR 07.2 SAR 16.2 Control unit: electromechanic
AC 01.2 Intrusive Technical data
