10.3 Fuses
10.3.1 Fuses within the actuator controls
Fuses used
F1/F2
Primary fuses on power supply unit
AUMA art. no.F1/F2G fuse
6.3 x 32 mmSize
K002.2771 A T; 500 VReversing contactors
Power supply 500 V
K002.6652 A FF; 690 VReversing contactors
Power supply > 500 V
K002.2771 A T; 500 VThyristor units for motor power up to 1.5 kW
Thyristor units for motor power up to 3.0 kW
Thyristor units for motor power up to 5.5 kW
F3
Internal 24 V DC supply
AUMA art. no.F3G fuse according to IEC 60127-2/III
5 x 20 mmSize
K006.1062.0 A T; 250 VVoltage output (power supply unit) = 24 V
K006.1062.0 A T; 250 VVoltage output (power supply unit) = 115 V
F4
Internal 24 V AC supply (115 V AC) for:
Heater, switch compartment, reversing contactors control
PTC tripping device
for 115 V AC also control inputs OPEN - STOP - CLOSE
AUMA art. no.F4G-fuse according to IEC 60127-2/III
5 x 20 mmSize
K001.1841.25 A T; 250 VVoltage output (power supply unit) = 24 V
Voltage output (power supply unit) = 115 V
F5
Automatic reset fuse as short-circuit protection for external 24 V DC supply for
customer (see wiring diagram)
Replace fuses F1/F2
Hazardous voltage!
Risk of electric shock.
Disconnect device from the mains before opening.
55
SA 07.2 SA 16.2/SAR 07.2 SAR 16.2 Control unit: electromechanic
AC 01.2 Intrusive Corrective action
