AUMA AUMATIC AC 01.2 Operation Instructions

12.2 Features and functions of actuator controls
For mains voltage and mains frequency, refer to name plates at the controls and the motor
Permissible variation of the mains voltage: ±10 %
Permissible variation of the mains frequency: ±5 %
Option: Permissible variation of the mains voltage: ±30 %
Power supply
Mains frequency
24 V DC +20 % / –15 %
Current consumption: Basic version approx. 250 mA, with options up to 500 mA
The external power supply must have a reinforced insulation against the mains voltage in
accordance with IEC 61010-1 and may only be supplied by a circuit limited to 150 VA in ac-
cordance with IEC 61010-1.
External supply of the electro-
nics (option)
Current consumption of the controls depending on the mains voltage:
For permissible variation of mains voltage by ±10 %:
●
100 to 120 V AC = max. 740 mA
●
208 to 240 V AC = max. 400 mA
●
380 to 500 V AC = max. 250 mA
●
515 to 690 V AC = max. 200 mA
For permissible variation of mains voltage by ±30 %:
●
100 to 120 V AC = max. 1,200 mA
●
208 to 240 V AC = max. 750 mA
●
380 to 500 V AC = max. 400 mA
●
515 to 690 V AC = max. 400 mA
Motor current consumption: Refer to motor name plate
Current consumption
Category III according to IEC 60634-4-443Overvoltage category
The controls are designed for the rated motor power, refer to motor name plateRated power
Standard:
Reversing contactors (mechanically and electrically interlocked) for motor power up to power
class A1
Options:
●
Reversing contactors (mechanically and electrically interlocked) for motor power up to
power class A2
●
Thyristor unit for mains voltage up to 500 V AC (recommended for modulating actuators)
for AUMA power classes B1, B2 and B3
Switchgear
1) 2)
Standard:
Via digital inputs OPEN, STOP, CLOSE, EMERGENCY (via opto-isolator, OPEN, STOP,
CLOSE with one common), respect minimum pulse duration for modulating actuators
Option:
Additional enable inputs for directions OPEN and CLOSE
Control
Standard:
24 V DC, current consumption: approx. 10 mA per input
Options:
48 V DC, current consumption: approx. 7 mA per input
60 V DC, current consumption: approx. 9 mA per input
110 V DC, current consumption: approx. 8 mA per input
115 V DC, current consumption: approx. 15 mA per input
115 V AC, current consumption: approx. 15 mA per input
Voltage and current values for
control inputs
3)
62
SA 07.2 – SA 16.2/SAR 07.2 – SAR 16.2 Control unit: electromechanic
Technical data AC 01.2 Intrusive
