Features and functions
●
Valve overload protection: adjustable, results in switching off and generates fault signal
●
Motor temperature monitoring (thermal monitoring): results in switching off and generates fault indic-
ation
●
Monitoring the heater within actuator: generates warning signal
●
Monitoring of permissible on-time and number of starts: adjustable, generates warning signal
●
Operation time monitoring: adjustable, generates warning signal
●
Phase failure monitoring: results in switching off and generates fault signal
●
Automatic correction of rotation direction upon wrong phase sequence (3-ph AC current)
Monitoring functions
●
Electronic device ID with order and product data
●
Operating data logging: A resettable counter and a lifetime counter each for:
-
Motor running time, number of starts, torque switch trippings in end position CLOSED, limit
switch trippings in end position CLOSED, torque switch trippings in end position OPEN, limit
switch trippings in end position OPEN, torque faults CLOSE, torque faults OPEN, motor protection
trippings
●
Time-stamped event report with history for setting, operation and faults
●
Status signals according to NAMUR recommendation NE 107: "Failure", "Function check", "Out of
specification", "Maintenance required"
●
Torque characteristics (for version with MWG in actuator):
-
3 torque characteristics (torque-travel characteristic) for opening and closing directions can be
saved separately.
-
Torque characteristics stored can be shown on the display.
Diagnostic functions
PTC tripping device in combination with PTC thermistors within actuator motorStandard:Motor protection evaluation
Thermal overload relay in controls combined with thermoswitches within actuatorOption:
Protection of the actuator and control electronics against overvoltages on the fieldbus cables of up to 4
kV
Overvoltage protection (option)
AUMA Ex plug/socket connector with screw-type terminals (KP), max. 38 control terminals
/ max. supply voltage 525 V AC
Standard:Electrical connection
●
AUMA Ex plug/socket connector with terminal blocks (KES), increased safety Ex e
●
AUMA Ex plug/socket connector with terminal blocks (KES), flameproof enclosure Ex
d
●
AUMA Ex plug/socket connector (KT); screw-type motor terminals; push-in type control
terminals
Options:
Metric threadsStandard:Threads for cable entries
Pg-threads, NPT-threads, G-threadsOptions:
Refer to name plateWiring diagram
Settings/programming the Modbus RTU interface
Baud rate, parity and Modbus address are set via the display of actuator controlsSetting the Modbus RTU interface
General data of the Modbus RTU interface
Modbus RTU according to IEC 61158 and IEC 61784Communication protocol
●
Line (fieldbus) structure.When using repeaters, tree structures can also be implemented.
●
Coupling and uncoupling of devices during operation without affecting other devices is possible.
Network topology
Twisted, screened copper cable according to IEC 61158Transmission medium
EIA-485 (RS-485)Fieldbus interface
Redundant line topology:
Possible cable length with repeat-
er (total network cable length)
Max. cable length (segment
length) without repeater
Baud rate (kbit/s)
approx. 10 km1,200 m9.6 – 115.2
Redundant ring topology:
Max. possible cable length of re-
dundant loop
Max. cable length between actuat-
ors (without repeater)
Baud rate (kbit/s)
approx. 290 km1,200 m9.6 – 115.2
Transmission rate/cable length
Modbus slave, e.g. devices with digital and/or analogue inputs/outputs such as actuators, sensorsDevice types
100
SAEx 07.2 – SAEx 16.2/SAREx 07.2 – SAREx 16.2 Control unit - electromechanical
Technical data ACExC 01.2 Intrusive Modbus RTU
