AUMA SAR 07.2 User Manual

Descriptions referring to name plate indications
Type designation
Table 1:
Description of type designation (with the example of SA 07.2-F07)
-F1007.2
Type SA = Multi-turn actuators for open-close duty
Type SAR = Multi-turn actuators for modulating duty
Size
These instructions apply to sizes 07.2, 07.6, 10.2, 14.2, 14.6, 16.2
07.2
Flange sizeF10
Table 2:
Description of actuator controls type designation (with the example of AC 01.2)
01.2AC
Type AC = AUMATIC actuator controlsAC
Size 01.201.2
Order number
The product can be identified using this number and the technical data as well as
order-related data pertaining to the device can be requested.
Please always state this number for any product inquiries.
On the Internet at http://www.auma.com > Service & Support >myAUMA, we offer
a service allowing authorised users to download order-related documents such as
wiring diagrams and technical data (both in German and English), inspection certificate
and the operation instructions when entering the order number.
Actuator serial number
Table 3:
Description of serial number (example of 0522MD12345)
MD123452205
Positions 1+2: Assembly in week = week 0505
Positions 3+4:Year of manufacture = 202222
Internal number for unambiguous product identificationMD12345
Actuator terminal plan
Position 9 after TPA: Position transmitter version
I, Q = MWG (magnetic limit and torque transmitter)
AUMA power class for
switchgear
The switchgear used in the actuator controls (reversing contactors/thyristors) are
classified according to AUMA power classes (e.g. A1, B1, ....).The power class
defines the max. permissible rated power (of the motor) the switchgear has been
designed for.The rated power (nominal power) of the actuator motor is indicated in
kW on the motor name plate. For the assignment of the AUMA power classes to the
nominal power of the motor types, refer to the separate electrical data sheets.
For switchgear without assignment to any power classes, the actuator controls name
plate does not indicate the power class but the max. rated power in kW.
Control
Table 4:
Control examples (indications on actuator controls name plate)
DescriptionInput signal
Control via DeviceNet interfaceDeviceNet
Control via DeviceNet interface and control voltage for OPEN - CLOSE control
via digital inputs (OPEN, STOP, CLOSE)
DeviceNet/24 V DC
Data Matrix code
When registered as authorised user, you may use our AUMA Assistant App to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order number or serial number.
11
SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive DeviceNet Name plate
