Features and functions
Metric threadsStandard:Threads for cable entries
Pg-threads, NPT-threads, G-threadsOption:
Terminal plan according to order number enclosed with deliveryTerminal plan
B1 according to EN ISO 5210Standard:Valve attachment
A, B2, B3, B4, C, D according to EN ISO 5210
A, B, D, E according to DIN 3210
C according to DIN 3338
Option:
Special valve attachments: AF, AK, AG, B3D, ED, DD, IB1, IB3
A prepared for permanent lubrication of stem
Electronic control unit
Magnetic limit and torque transmitter (MWG)
Turns per stroke: 1 to 500 (standard) or 10 to 5,000 (option)
Non-Intrusive setting
Via actuator controlsPosition feedback signal
Via actuator controlsTorque feedback signal
Continuous self-adjusting indication with symbols OPEN and CLOSEDMechanical position indicator
Blinking signal via actuator controlsRunning indication
Resistance type heater with 5 W, 24 V ACHeater in switch compartment
Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 2 000 m above sea level
> 2,000 m above sea level, on request
Installation altitude
Refer to actuator name plateAmbient temperature
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
IP68 with AUMA DC motor
IP68 with AUMA 3-phase AC motor
IP68 with 1-phase AC motors of types VB..., AE..., VE..., AC..., VC...
For special motors, differing enclosure protection is possible
Standard:Enclosure protection in accordance
with IEC 60529
Terminal compartment additionally sealed against interior of actuator (double sealed)Option:
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: Maximum 8 m head of water
●
Continuous immersion in water: maximal 96 hours
●
Up to 10 operations during immersion
●
Modulating duty is not possible during immersion.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to
IEC 60664-1
2 g, 10 to 200 Hz (AUMA NORM), 1 g, 10 to 200 Hz (for actuator with mounted AM or AC AUMA actu-
ator controls)
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this. Indications apply to actuator with AUMA 3-phase AC motor and AUMA plug/socket
connector.They are not valid in combination with gearboxes.
Vibration resistance according to
IEC 60068-2-6
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Options:
KX-G : same as KX, however aluminium-free version (outer parts)
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Option:
Two-layer powder coating
Two-component iron-mica combination
Coating
91
SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive DeviceNet Technical data
