AUMA SAR 07.2 User Manual

Features and functions
●
Valve overload protection: Adjustable, results in switching off and generates fault signal
●
Motor temperature monitoring (thermal monitoring): Results in switching off and generates fault
signal
●
Monitoring the heater within actuator: Generates warning signal
●
Monitoring of permissible on-time and number of starts: Adjustable, generates warning signal
●
Operating time monitoring: Adjustable, generates warning signal
●
Phase failure monitoring: Results in switching off and generates fault signal
●
Automatic correction of rotation direction upon wrong phase sequence (3-ph AC current)
Monitoring functions
●
Electronic device ID with order and product data
●
Operating data logging: A resettable counter and a lifetime counter each for:
-
Motor running time, number of starts, torque switch trippings in end position CLOSED, limit
switch trippings in end position CLOSED, torque switch trippings in end position OPEN, limit
switch trippings in end position OPEN, torque faults CLOSE, torque faults OPEN, motor protection
trippings
●
Time-stamped event report with history for setting, operation and faults
●
Status signals according to NAMUR recommendation NE 107: "Failure", "Function check", "Out of
specification", "Maintenance required"
●
Torque characteristics (for version with MWG in actuator):
-
3 torque characteristics (torque-travel characteristic) for opening and closing directions can be
saved separately.
-
Torque characteristics stored can be shown on the display.
Diagnostic functions
Monitoring the motor temperature in combination with thermoswitches within actuator
motor
Standard:Motor protection evaluation
●
Thermal overload relay in controls combined with thermoswitches within actuator
●
PTC tripping device in combination with PTC thermistors within actuator motor
Options:
Protection of the actuator and control electronics against overvoltages on the fieldbus cables of up to 4
kV
Overvoltage protection (option)
AUMA plug/socket connector with screw-type connectionStandard:Electrical connection
Gold-plated control plug (sockets and plugs)Option:
Metric threadsStandard:Threads for cable entries
●
Pg-threads, NPT-threads, G-threads
●
Terminals or crimp-type connection
Options:
Refer to name plateWiring diagram
Setting/programming the fieldbus interface
Supported baud rates: 125 kbit/s, 250 kbit/s and 500 kbit/s. Setting via DIP switchesBaud rate setting
Setting the address via DIP switchSetting the DeviceNet address
(MAC/NODE ID)
Actuator controls is capable of exchanging data with the DCS by means of different assembly objects:
●
Input data (Produced Data):
Standard Input, Extended Input, Extended one analogue Input, Extended two analogue Input, En-
hanced Input, Process Input Data 1, Process Input Data 2, Process Input Data 3
●
Output data (Consumed Data):
Standard Output, Process Output Data 1
Depending on the configuration, length and content of the data interface differ. The configuration is set
via rotary switches S4 and S5. In addition, the basic connection type within actuator controls is defined
to AM Triple Play or AC .1.
Configurable process representation
95
SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive DeviceNet Technical data

AUMA SAR 07.2 Specifications

General

Brand	AUMA
Model	SAR 07.2
Category	Controller
Language	English
