AUTEC Dynamic Plus Series User Manual

AUTEC - Dynamic Plus series
Technical data 13
LIUDJR000_eng-00
A Display or LED (if present)
B LEDs
C
Actuators (joysticks, selectors,
pushbuttons)
D STOP pushbutton
E Transmitting Unit identi󰘰cation plate
F Technical data plate
G
Radio Remote Control identi󰘰cation
plate (if the “ID internal tx memory” is
present)
H Connector for cable control (if present)
J Battery
K
Radio Remote Control identi󰘰cation
plate (if the “Key ID 0-1” is present)
L Power keyswitch
M START pushbutton
N Battery housing
P Connector for "ID internal tx memory"
4 Technical data
Power supply (battery MBM06MH) ......................................................................... 7.2V
Power supply (battery LPM02) ............................................................................... 7.4V
Power supply (battery LPM04) ............................................................................... 7.4V
Antenna .................................................................................................................. internal
Housing material .......................................................................................... PA 6 (20%fg)
Protection degree ....................................................................................... IP65 (NEMA 4)
Dimensions .................................................................. 260x200x190mm (10.2x7.9x7.5In)
Weight ........................................................................................................... 2.0kg (4.4Lb)
Run time at 20°C (68°F):
- with battery MBM06MH ............................................................................................... 11h
- with battery LPM02 .................................................................................................. 18.5h
- with battery MBM06MH and monochromatic display 2.7" .............................................. 9h
- with battery LPM02 and monochromatic display 2.7" ................................................... 15h
- with battery LPM04 ..................................................................................................... 35h
- with battery LPM04 and monochromatic display 2.7" ................................................... 28h
- with battery LPM04 and colour display 4.3" ................................................................... 8h
