Light and acoustic warning signals
AUTEC - Dynamic Plus series
The meaning of signals provided by the green LED [B], when the red LED [A] is o󰘯, are
described in the following table.
Light signals Meaning
The green LED is o󰓐.
The red LED is o󰓐.
The Transmitting Unit is o󰘯.
The green LED blinks fast.
The red LED is o󰓐.
The Transmitting and Receiving Unit do not
communicate.
The green LED repeats the sequence: a
blink and a pause.
The red LED is o󰓐.
The Radio Remote Control is started and the Units
communicate via radio link in the 863-870MHz
frequency band.
The green LED repeats the sequence:
two blinks and a pause.
The red LED is o󰓐.
The Radio Remote Control is started and the Units
communicate via radio link in the 915-928MHz
frequency band.
The green LED repeats the sequence:
three blinks and a pause.
The red LED is o󰓐.
The Radio Remote Control is started and the Units
communicate via cable control.
The meaning of the green [B] and red [A] LED signals cannot be modi󰘰ed.
7.2 Acoustic signals
The DJR Transmitting Unit has an acoustic signal device that activates when:
- The battery is nearly 󰘱at,
- the Transmitting Unit has been on for eight hours,
- The Transmitting Unit does not work correctly,
- during the Radio Remote Control start-up, the STOP pushbutton is pressed or damaged,
- during the Radio Remote Control start-up, the SAFETY command is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands D2-D20 is activated
(see Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands A1-A8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands H1-H8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands L1-L8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, the battery is 󰘱at.
The acoustic signal device activates whenever the red LED [A] illuminates. The meaning of
red LED [A] signals and of the acoustic signal device, and the possible actions to adopt are
described in chapter 11.
The meaning of the acoustic signals cannot be modi󰘰ed.
