26
LIUDJR000_eng-00
General operating instructions
AUTEC - Dynamic Plus series
8.11 Radio link interruption
When the radio link is incorrect or interrupted for a certain time lapse ("Passive Stop" indicated
in the Technical Data Sheet), the automatic stop function activates (see paragraph "Control
devices" in "Part A" of the Manual).
The green LED on the Transmitting Unit blinks fast.
The POWER LED on the Receiving Unit illuminates steadily.
To start the Radio Remote Control, press the START pushbutton until the green LED repeats
one of the following sequences: one or two blinks and a pause. If the red LED lights up,
refer to chapter 11.
When the green LED repeats one of the following sequences: one or two blinks and a pause,
the Radio Remote Control is active and it can send commands and activate the Machine.
8.12 Transmitting Unit automatic switch o󰓐
The Transmitting Unit automatically switches o󰘯 when:
- the battery is 󰘱at (see paragraph 8.12.1),
- the Radio Remote Control is not used for a certain time (see paragraph 8.12.2),
- the Transmitting Unit is powered and never switched o󰘯 for eight hours non-stop (see
paragraph 8.12.3).
The green LED on the Transmitting Unit blinks fast.
The POWER LED on the Receiving Unit illuminates steadily.
To start the Radio Remote Control, press the START pushbutton until the green LED repeats
one of the following sequences: one or two blinks and a pause. If the red LED lights up,
refer to chapter 11.
When the green LED repeats one of the following sequences: one or two blinks and a pause,
the Radio Remote Control is active and it can send commands and activate the Machine.
8.12.1 Low battery
The Transmitting Unit indicates if the battery is not su󰘲ciently charged (the red LED blinks
and an acoustic signal sounds).
The Transmitting Unit automatically switches o󰘯 after 3.5 minutes after the onset of the signal.
It is necessary to bring the Machine to a safe state and replace the battery with a charged
one (see paragraph 8.7).
