General operating instructions
AUTEC - Dynamic Plus series
The cable control must only be connected and disconnected when the Transmitting
Unit is o.
When you nish working with the cable control, disconnect the cable from the
Transmitting Unit and from the Machine, and protect the connectors with their caps.
Follow this procedure to control the Machine with the cable control:
1. power on the Receiving Unit respecting the voltage limits provided in the technical data
(see "Part D" of the Manual). The POWER LED switches on,
2. make sure that the battery is inside the Transmitting Unit and leave it there even though
the power supply comes from the Receiving Unit via the cable control. The battery is
not, in any case, recharged through the cable control: it can only be recharged through
its appropriate Battery Charger provided together with the system.
3. connect the cable control to its connector in the Receiving Unit (or where arranged by
the Machine Manufacturer),
4. connect the cable control to its connector on the Transmitting Unit,
5. insert the power keyswitch in the Transmitting Unit (see paragraph 8.1.3),
6. press the START pushbutton and hold it down until the green LED repeats the sequence:
three blinks and a pause.If the red LED lights up, refer to chapter 11.
When the green LED repeats the sequence: three blinks and a pause, the Radio Remote
Control is active and it can send commands and activate the Machine.
When working with the cable control the radio link is cut o:
8.16 BACK-UP UNIT
If the Transmitting Unit cannot be used, it can be replaced with a Transmitting Unit called
"BACK-UP UNIT"; you need to ask for it from Autec.
It is identical to the Unit that cannot be used any more; the only dierence is the presence
of the plate “BACK-UP UNIT” on the battery housing.
Insert in the "BACK-UP UNIT" the “Key ID 0-1” or the “ID internal tx memory”
of the Transmitting Unit that cannot be used any longer and perform the
address storage procedure described below.
8.16.1 Address storage
With fully charged battery and power keyswitch in the "BACK-UP UNIT", perform this procedure:
1. press the STOP pushbutton,
2. press the START pushbutton and hold it down until the green LED switches o,
3. unlock the STOP pushbutton,
It is now possible to start the Radio Remote Control and control the Machine with the "BACK-
UP UNIT" Transmitting Unit.
