7
Camera (rear)
8.0 Megapixel, AF with Flashlight
Sensors
Gravity Accelerometer, Ambient Light
Sensor (ALS)
Audio
Input/output
Microphone
Dual Speakers
3-Band 3.5 mm stereo/standard headset
jack
Power and
Battery
11000 mAh 3.7 V lithium-polymer battery
Charging via 12 V AC/DC power supply with
the temperature between 0°C and 45°C
Input Voltage
12 V (9-24 V)
Power
Consumption
6.5 W
Operating Temp.
0 to 50°C (32 to 122°F)
Storage Temp.
-20 to 60°C (-4 to 140°F)
Dimensions
(WxHxD)
300 mm (11.81”) x 220 mm (8.66”) x 50 mm
(1.97”)
Weight
NW: 1.42 kg (3.13 lb.)
GW: 8.655 kg (19.08 lb.)
Protocols
ISO 9142-2, ISO 14230-2, ISO 15765-4,
K/L-Line, Flashing Code, SAE-J1850 VPW,
SAE-J1850 PWM, CAN ISO 11898,
Highspeed, Middlespeed, Lowspeed and
Singlewire CAN, GM UART, UART Echo
Byte Protocol, Honda Diag-H Protocol, TP
2.0, TP 1.6, SAE J1939, SAE J1708, Fault-
Tolerant CAN
