Autel MaxiSys ADAS - Technical Specifications

10
Technical Specifications
Table 2-2 MaxiFlash Elite Specifications
Item
Description
Communications
Wireless BT V2.1 + EDR
USB 2.0
Wireless
Frequency
Wireless BT V2.1+EDR, 2.4GHz
Input Voltage
Range
12 VDC to 24 VDC
Supply Current
170 mA @ 12 VDC
100 mA @ 24 VDC
Operating Temp.
0°C to 60°C (ambient)
Storage Temp.
-65°C to 100°C (ambient)
Dimensions
(L x W x H)
149 mm (5.87”) x 86 mm (3.38”) x 35 mm
(1.28”)
Weight
290 g (0.64 lb.)
Accessories Kit
Main Cable
The MaxiFlash Elite can be powered through the Main Cable when connected
to an OBD II/EOBD compliant vehicle. The Main Cable connects the
MaxiFlash Elite to the vehicle’s data link connector (DLC), through which the
MaxiFlash Elite can transmit vehicle data to the tablet.
Figure 2-6 Main Cable – 1.5 m in length
