NOTE
Damage to the vehicle electronic control module (ECM) may occur if
communication is disrupted. Make sure that all connections, such as data cable,
USB cable, and wireless or wired network, are properly connected at all times
during testing. Exit all tests before disconnecting the test cable or powering
down the tool.
To exit the Diagnostics application
1. From an active diagnostic screen, tap the Back or ESC functional button
to exit a diagnostic session step-by-step; Or
2. Tap the Vehicle Swap button on the diagnostics toolbar to return to the
Vehicle Menu screen.
3. From the vehicle menu screen, tap the Home button on the top toolbar; or
tap the Back button on the navigation bar at the bottom of the screen. Or
tap the Home button on the diagnostics toolbar to exit the application
directly to the MaxiSys Job Menu.
Now, the Diagnostics application is no longer communicating with the vehicle
and it is safe to open other MaxiSys applications, or exit the MaxiSys
Diagnostic System and return to the Android System’s Home screen.
Diagnostics
The ADAS application provides calibration functions for vehicles equipped
with Advanced Driver-Assistance Systems.
If the camera, radar or other ADAS component on a vehicle is not working
properly, use this ADAS function to calibrate these components and correct
their operating status.
Establish Vehicle Communication
The Diagnostics operations require connecting the MaxiSys ADAS Diagnostic
Platform to the test vehicle through the MaxiFlash Elite using the main cable
and test adapters (for non-OBD II vehicles). To establish proper vehicle
communication to the tablet, please perform the following steps:
1. Connect the MaxiFlash Elite to the vehicle’s DLC for both communication
and power source.
2. Connect the MaxiFlash Elite to the tablet via BT pairing, or USB
connection.
3. When the above steps are completed, check the VCI navigation button at
