AUTOFRY Models FFG-10 and MTI-10 Operator's Manual
Table of Figures
Figure 1 Re-set high limit 2
Figure 2 Install legs 3
Figure 3A Remove food entry chute 4
Figure 3B Separate food entry chute 4
Figure 4 Filter cover plate 5
Figure 5 Charcoal filter 5
Figure 6 Oil pot installed 6
Figure 7 Install heater box assembly 6
Figure 8A RTD plug 7
Figure 8B Thermocouple plug 7
Figure 9 Install food exit chute 8
Figure 10A Basket rod and cam 9
Figure 10B Basket rod and receiver clip 9
Figure 11 Completed installation 9
Figure 12A FFG-10 Fire actuation cable 20
Figure 12B MTI-10 Fusable link and cable 20
Figure 13A Removable stack cover / fire damper 22
Figure 13B Fan section 22
MTI FormOP-0010 Rev. 005 5/98 E167654
ii
