AUTOFRY Models FFG-10 and MTI-10 Operator's Manual
AUTOFRY Installation.
You will need assistance to position and install the AUTOFRY. The approximate
weight of the unit is 180 pounds
Remove and save the packing materials.
Be sure to inspect the AUTOFRY. Your AUTOFRY has left the factory in perfect
condition and has been packaged to withstand rugged travel. However, in the event
that you observe damage to the AUTOFRY, you should contact the carrier
immediately and report any damages. Be sure that you have your signed bill of
lading.
Take out the removable components from inside the AUTOFRY.
• 4 adjustable legs
• " A 36" drain hose
• Food exit chute
• Wire food basket
• * Heater box assembly
• Oil pot
• Oil catch tray
* Check the red high limit re-set button on the bottom of the heater box
assembly by fully depressing it with the eraser end of a pencil. If the limit has been
tripped you will hear a "click" (see Figure 1).
MTI FomnOP-0010 Rev. 005 5/98
E167654
