p 15/58
Technical Manual NAM-BL4x-MT-EN-C
The information in this document is the property of Automatic Systems and is confidential. The consignee withholds from using it for anything other than the use of the products or the execution of the
project to which they belong and withholds from communicating it to third parties without prior written agreement from Automatic Systems. Document subject to change without prior notice.
Analog. Fault
The analogue sensor gives 0 or 1023 during minimum
100 ms. This may result from a defective wiring, a wrong
positioning of the sensor in front of its cam, a defective
sensor, etc.
OP Power Cut
Unlocking of the obstacle following an outage of the
supply voltage (if QUICK START ► Power Fail OP
► ON).
OP Power Blip
Unlocking of the obstacle following a micro-outage of the
supply voltage (the voltage drops to 0 V during a few
milliseconds) (if QUICK START ► Power Fail OP ► ON).
In this state, the obstacle is STOPPED but still
operational, because the supply voltage has returned. The
apparatus waits for the next command to execute a
movement.
CoolingMotor ON
Start-up of the motor cooling fan.
Note
: This message is only displayed if the Cooling – Log
(below) is ON.
CoolingMotor OFF
Stopping of the fan that cools the motor.
Note
: This message is only displayed if the Cooling – Log
(below) is ON.
Stop Time Out
Elapse of the delay defined under the Max Stop
parameter of the TIMING menu for the regulation of the
obstacle position with regard to the Stop.
Download Chg Lv1
Downloading a version of the control board program that
differs from the one previously installed.
As the difference is of level 1 (minor index modification or
revision), the parameters continue operate with their value
saved in MEM1.
Download Chg Lv2
Downloading a version of the control board program that
differs from the one previously installed.
As the difference is of level 2 (modification of the version
or the evolution), all of the parameters are returned to
their default values.
WARNING
: it is then necessary to set the parameters to
the actual configuration of the equipment and to save
them in MEM1.
Note
: it would be wise to keep the parameters values
before changing the program version: Communication
parameter Extract Param (Technician level access).
Download Chg Lv3
Downloading a version of the control board program that
differs from the one previously installed.
As the difference is of level 3 (modification of the type), all
of the parameters are returned to their default values and
the counters are reset to 0.
WARNING
: it is then necessary to set the parameters to
the actual configuration of the equipment and to save
them in MEM1.
Note
: it would be wise to keep the parameters values
before changing the program version: Communication
parameter Extract Param (Technician level access).
