Unlock BL4x Er
Only with locking of the arm option for BL4x. The inductive
sensor has not detected the release of the lock within the
3 seconds following the open or close request: check
whether the locking pin is pressing on the locking clips,
preventing them form opening, or whether the sensor is
defective.
Close Status
Cases when the obstacle is prevented from closing during
a close request:
OK
Normal closure.
PS1 Activated
A sensor (loop/cell) detects a presence or a fault in the
circuit. In the latter case:
Check whether the sensor is plugged into the
corresponding connector and whether it is functioning
properly.
Check whether the sensor is properly connected.
Check whether the sensors are programmed correctly
(SENSOR FUNCTION menu).
PS2 Activated
PS3 Activated
PS4 Activated
Lock OP Hold
Check why the Lock Open command is being maintained
on the control board connector block.
Safe Arm Activ
Activation of the Safety Arm sensor (only with the rubber
protection profile option: rubber strip that detects when the
arm makes contact with a vehicle):
Check whether the arm safety sensor is functioning
properly.
Check whether the Safety Arm parameter is
programmed correctly (Options menu).
PWF Open Activ
Setting of the PWF Open Activ parameter of the
OPTIONS menu to ON, that is to say that during
activation the obstacle opens and waits for the activation
of a close or lock-close command.
Note
: the closure loops are not taken into account for
closing in this case.
Lock Open LCD
The Test Mode parameter of the TEST menu is not set to
Deactivated.
Delay Befor CL
Wait for the delay programmed under the Delay Befor. CL
parameter under the TIMING menu to elapse.
Open Cmd Hold
Check why the open command is being maintained on the
control board connector block.
Stop Cmd Hold
Check why the stop command is being maintained on
the control board connector block.
Check whether the Stop Cmd parameter is
programmed correctly (Options menu).
Reader A Hold
Check why the Reader A command is being maintained
on the control board connector block.
Reader B Hold
Check why the Reader B command is being maintained
on the control board connector block
