Autonics TM Series - Input Type; Input Temperature Sensor Unit

6 Parameter Settings and Functions
42 © Copyright Reserved Autonics Co., Ltd.
6.1.2 Input type
This product supports multiple input types, making it possible for the user to choose from
thermocouples, resistors, and analog voltage/current. Different sensors can be designated to
each channel.
CH1 input type = KCA.H, CH2 input type = JIC.H
Setting group Parameter Setting range
Factory
default
Unit
Initial Setting Input Type
Refer to 6.1.1 Input
type and
temperature range
K(CA).H -
 When changing input type settings, the high-limit and low-limit values of SV are
automatically changed to max/min values of operational temperature range of the modified
input type. You must reset these values. (SV, Multi SV No, SV-0 to SV-3 and input
correction are initialized.) However, measurement units remain the same.
 If the measured value is out of the input range, external device displays HHHH (high-limit),
LLLL (low-limit) and displays OPEN when the sensor is not connected.
6.1.3 Input temperature sensor unit
When selecting the temperature sensor input options, you can set the desired units of operation
temperature/display temperature.
Setting group Parameter Setting range
Factory
default
Unit
Initial Setting Unit ℃, ℉ ℃ -
When modifying the temperature units, setting values of the related parameters remain the same
as the existing values, and SV, Multi SV No., SV-0 to SV-3, SV high-limit/low-limit, and input
correction will be initialized.
