Autonics TM Series - 2 Specifications

2 Specifications
© Copyright Reserved Autonics Co., Ltd. 25
2 Specifications
Series
TM2
TM4
Number of channels
2 channels
(insulated each channel –
dielectric strength 1,000VAC)
4 channels
(insulated each channel –
dielectric strength 1,000VAC)
Power supply 24VDCᜡ
Allowable voltage range 90 to 110% of rated voltage
Power consumption Max. 5W (for max. load)
Display method
None- parameter setting and monitoring is available at external
devices (PC, PLC, etc.)
Input
type
Thermocouple
K(CA), J(IC), E(CR), T(CC), B(PR), R(PR), S(PR), N(NN), C(TT),
G, (TT), L(IC), U(CC), Platinel II
RTD DPt100Ω, JPt100Ω (permissible line resistance max. 5Ω)
Sampling period
50 ms
(2 channel simultaneous
sampling)
100 ms
(4 channel simultaneous
sampling)
Meatured
accuracy
Thermocouple
※
1
(PV ±0.5% or ±1℃, select the higher one) ±1-digit max.
RTD
CT input ±5% F.S. ±1-digit max. -
Current output ±1.5% F.S. ±1-digit max. -
Influence of
temp.
※
2
Thermocouple
(PV ±0.5% or ±2℃, select the highter one) ±1-digit max.
(Thermocouple input max. -100℃ is within ±5℃)
●Thermocouple B, R, S, C, G, L, U:
(PV ±0.5% or ±5℃, select the highter one) ±1-digit max.
RTD
Control
Output
Relay
250VACᜠ 3A 1a
SSR
Max. 12VDCᜡ ±3V 30mA Max. 22VDCᜡ ±3V 30mA
Current
Selectable DC 4-20mA or
DC 0-20mA
(load resistance max. 500Ω)
-
Control
type
Heating, Cooling
ON/OFF control, P, PI, PD, PID control
Heating & Cooling
Option
output
Alarm
250VACᜠ 3A 1a
-
Communication RS485 communication output (Modbus RTU method)
Option
input
CT input
0.0-50.0A (primary current
measurement range)
※CT ratio: 1/1000
-
Digital input
● Contact input: ON max. 1kΩ,
OFF min. 100kΩ
● Solid-state input: ON residual
voltage max. 1.5VDCᜡ, OFF
leakage current max. 0.1mA
● Outflow current:
Approx. 0.5mA per input
-
Hysteresis
1 to 100℃/℉ (0.1 to 100.0℃/℉) variable
Proportional band (P)
0.1 to 999.9℃/℉
