Autonics TM Series User Manual

2 Specifications
26 © Copyright Reserved Autonics Co., Ltd.
Series
TM2
TM4
Integral time (I) 0 to 9999 sec
Derivative time (D) 0 to 9999 sec
Control period 0.1 to 120.0 sec (only relay and, SSR drive output type)
Manual reset 0.0 to 100.0%
Relay
life cycle
Mechanical Min. 10,000,000 operations
Electrical Min. 100,000 operations (250VAC 3 A resistance load)
Insulation resistance 100 MΩ (at 500VDC megger)
Insulation type
Double insulation or reinforced insulation
(mark: , dielectric strength between measurement part and
power part: 1kV)
Dielectric strength
1,000VAC 50/60Hz for 1 min (between input terminals and power
terminals)
Vibration
0.75mm amplitude at frequency of 5 to 55Hz (for 1 min) in each
X, Y, Z direction for 2 hours
Noise resistance
±0.5kV the square wave noise (pulse width: 1 ㎲) by the noise
simulator
Environ-
ment
Ambient temperature
-10 to 50℃, storage: -20 to 60℃
Ambient humidity 35 to 85%RH, storage: 35 to 85%RH
Accessories
Expansion connector: 1,
Power/Comm. connector: 1 (only for basic module)
Approval
Weight
※
3
Basic module
Approx. 217g
(Approx. 152g)
Approx. 239g
(Approx. 174g)
Expansion module
Approx. 208g
(Approx. 143g)
Approx. 231g
(Approx. 166g)
※1. In case of thermocouple K, J, E, T, N, it is below -100℃ and L, U, Platinel II, it is below
±2℃ ±1-digit.
In case of thermocouple B, display accuracy cannot be ensured under 400℃.
In case of thermocouple R, S, it is below 200℃ and C, G, it is max. 3℃ ±1-digit.
※2. Applied when it is for out of room temperature (23±5℃) range.
※3. The weight includes packaging. The weight in parenthesis is for unit only.
※Environment resistance is rated at no freezing or condensation.
