Autonics TM Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 81
6.6 Monitoring function
6.6.1 Control output MV monitoring
Monitors and displays the current control output MV.
6.6.2 Heating MV monitoring
Displays the current heating MV during heating control or heating and cooling control. Users
may manually adjust the MV to control the temperature.
 Measurement range: 0.0 to 100.0%
6.6.3 Cooling MV monitoring
Displays the current cooling MV during cooling control or heating and cooling control. Users may
manually adjust the MV to control the temperature.
 Measurement range: 0.0 to 100.0%
6.6.4 Heater current monitoring
A feature that monitors and displays the current of a heater (load) being controlled by control
output.
 Measurement range: 0.0 to 50.0A
The current value of a heater (load) is measured and displayed through the current transformer.
Setting group Parameter Setting range
Factory
default
Unit
Monitoring Heating_MV 0.0 to 100.0 - %
Monitoring Cooling_MV 0.0 to 100.0 - %
Monitoring CT1_Heater Current 0.0 to 50.0 - A
Monitoring CT2_Heater Current 0.0 to 50.0 - A
Availability of the heater current monitoring function is different by model and control output type.
Model Control output type Heater current monitoring
TM□-□□R□ (Relay output) Relay output ○
TM4□-□□S□
(SSR drive output)
ON/OFF control ○
Cycle control X
Phase control X
TM2□-□□C□
(Current or SSR drive output)
Current output X
SSR drive output ○
