Autonics TM Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 55
6.2.7 Manual control initial MV
If the baseline MV for manual control is configured to PRESET-MV, you can set the initial MV for
manual control.
Setting
group
Preceding condition Parameter Setting range
Factory
default
Unit
Control
Setting
Heating, Cooling, PID
Preset
Manual MV
0.0 to 100.0 0.0
%
Heating & Cooling, PID
-100.0 (Cool) to
100.0 (Heat)
0.0
When in heating and cooling control, a setting between 0.1 and 100.0 applies heating MV, and a
setting between 0.1 and -100.0 applies cooling MV.
6.2.8 Control output
If the control output type is a current or SSR drive output model, control output is supported at
the same time, so the user can choose a suitable output type.
Setting group Parameter Setting range
Factory
default
Unit
Initial Setting
Output(SSR_Curr)
Type
SSR, CURRENT SSR -
The relevant parameter will be activated only if the model is TM2-□□C□ (current or SSR drive
output type).
6.2.8.1 Current output range
If the control output is set to current output, you can select high and low-limit range for the
current output as either 4-20mA or 0-20mA.
Setting group Parameter Setting range
Factory
default
Unit
Initial Setting Current Output Range 0-20, 4-20 4-20 mA
If the model is TM2-□□C□ (current or SSR drive output type), the relevant parameter will be
activated only if the control output is set to current.
