Figure 2.12
On ALL Magnum tank configurations, optional multi-
switch kits are available to provide additional electrical
or switch closure signals during the regeneration or
backwash cycles. Coupled with the optional
breakaway cams, signals can be sent to external
system equipment at virtually any time while the
control/camshaft motor is running. Consult the
instruction sheet covering the multi-switch option for
additional application and programming information.
The instruction sheet is sent with the switch kit.
Normally Closed
Normally Open
Common
