6.0 Programming Tables
6.1 Table I - Level 1 Values
Level I Program Values for 962, 962F, 962TC, 962FTC, and 962M Controls
Level II, III values on following pages.
Description of
Program Values
Range of Values
Min.
Incre-
ment
Setting
Factory
Value
Units of
Measure
Notes
P1
Day of Week
Time of day
1:00 - 12:59 AM/PM
00:00 - 23:59
1 None hour:minute
Range depends
on value
selected for P13.
For day of week
Sun = 1, Mon =
2, Tues = 3, Wed
= 4, Thurs = 5,
Fri = 6, Sat = 7.
P2
Time of day to start
regeneration
1:00 - 12:59 AM/PM
00:00 - 23:59
1 None
hour:minute
Range depends
on value
selected for P13
For 962M, used
only if P15 = 1
P3 Hardness of water
3-250
30-2500
1
10
0
0
grains/gallon
(ppm)
Unit of measure
depends on
value selected
for P12
P4 Salt amount
5-1250
2-500
5
2
10
4
pounds
(kilograms)
Unit of measure
and factory value
depends on
value selected
for P12
P5 Capacity of unit
1-2600
0.1-260.0
1
0.1
0
0
kilograins
(kilograms)
Unit of measure
depends on
value selected
for P12
