10.5 Autotrol Drain Line Flow Control
Table 10.4 Autotrol Drain Line Flow Controls (5 gpm - 40 gpm)
Note: Drain Line Flow Controls above 40 gpm require external control installed in drain line.
Part Number
Flow Control Disk
Insert 1 Insert 2 Insert 3 Insert 4
gpm
m
3
/h
1040720 5 1.135 Blue Black Black Black
1040721 6 1.362 Red Black Black Black
1040722 7 1.589 Brown Black Black Black
1040723 8 1.816 Green Black Black Black
1040724 9 2.043 White Black Black Black
1040725 10 2.27 Blue Blue Black Black
1040726 11 2.497 Red Blue Black Black
1040727 12 2.724 Red Red Black Black
1040728 13 2.951 Brown Red Black Black
1040729 14 3.178 Brown Brown Black Black
1040740 15 3.405 Blue Blue Blue Black
1040741 16 3.632 Green Green Black Black
1040742 17 3.859 White Green Black Black
1040743 18 4.086 White White Black Black
1040744 19 4.313 White Orange Black Black
1040745 20 4.54 Blue Blue Blue Blue
1040746 21 4.767 Brown Brown Brown Black
1040747 22 4.994 Green Green Red Black
1040748 23 5.221 Green Green Brown Black
1040749 24 5.448 Red Red Red Red
1040730 25 5.675 Green Green White Black
1040731 26 5.902 White White Green Black
1040732 27 6.129 White White White Black
1040733 28 6.356 Brown Brown Brown Brown
1040734 29 6.583 Brown Brown Brown Green
1040735 30 6.81 Orange Orange Orange Black
1040736 31 7.037 Green Green Green Brown
1040737 32 7.264 Green Green Green Green
1040738 33 7.491 Green Green Green White
1040739 34 7.718 Green Green Green Orange
1040750 35 7.945 White Green Green Green
1040751 36 8.172 White White White White
1040752 37 8.399 White White White Orange
1040753 38 8.626 Orange Orange Orange Green
1040754 39 8.853 Orange Orange Orange White
1040755 40 9.08 Orange Orange Orange Orange
