1.0 Installation Profile Summary
Installation Date: ______________________________
Installation Location: ___________________________
Installer(s): ____________________________________
Phone Number:________________________________
Valve Number: _________________________________
Application Type: (Softener) (Filter) (Dealkalizer)
Water Source:
(Public Well) (Private Well)
(Surface Supply)
(Other)
Water Test Results:
Hardness:_______________ Iron:_______________
Other: ________________________________________
Misc:
Capacity: _______ Flow Rates:______ min. ____ max.
Tank Size: Diameter ________ Height: __________
Resin or Media Volume:_________________________
Resin or Media Type: ___________________________
Brine Tank Volume:_____________________________
Salt Setting per Regeneration: ___________________
Control Valve Configuration:
Valve Type:____________________________________
(Hard Water Bypass) (No Hard Water Bypass)
Refill Control:______________________________ gpm
Injector Control: ___________________________ gpm
Backwash Control: _________________________ gpm
Manual Control:
(Softener) (Filter)
Mechanical Timeclock:
(7 day) (12 day)
Salt Setting: __________________________________
Regeneration Frequency:
SM T W T F S
123456789101112
______________________________________________
______________________________________________
Impulse
(480) (Other) ___________________________________
Salt Setting:____________________________________
Electronic Demand Settings
P1 Time of Day _________________
P2 Time of Day Regen _________________
P3 Hardness of Water _________________
P4 Salt Amount _________________
P5 Capacity of Unit _________________
P6 Refill Control Value _________________
P7 Brine Draw Value _________________
P9 Backwash Time _________________
P10 Slow Rinse Time _________________
P11 Fast Rinse Time _________________
P12 Units of Measure _________________
P13 Clock Mode _________________
P14 Calendar Override _________________
P15 Reserve Type _________________
P16 Fixed Reserve Cap.
or Initial Ave. Value _________________
P17 Operation Type _________________
P18 Salt Change Lock Out _________________
P19 Flow Sensor Size _________________
P20 K-Factor or Pulse
Equivalent _________________
P21 Remote Regeneration
Switch Delay _________________
P22 Factory Use Only _________________
Twin Parallel Triple Parallel
Regeneration Type (P15): ___________
3 = Fixed Reserve with
Immediate Regeneration
Fixed Reserve (P16):____________% (0% only)
Twin Alternating
Regeneration Type (P15): ___________
0 = Immediate Regen
1 = Delayed Regen
Fixed Reserve (P16): _____________ %
