Autotrol Magnum Cv 942F User Manual

38
6.5 Table IID
Level II Program Values - Electronic Timeclock Filter (P17=7)
Parameter Description Range of Values
Min.
Increment
Factory Value
Units of
Measure
Notes
P1 Day of Week
and Time of day
(1-7) 1:00 - 12:59
AM or PM
Metric
(1-7) 0:00 - 23:59
(1 day)
1 minute
Current Day and
Time
Hour
Minute
Range depends on value selected for
P13
For day of week SUN=1, MON=2,
TUE=3, WED=4, THU=5, FRI=6,
SAT=7. THIS IS THE LEFT MOST
DIGIT ON THE DISPLAY
P2 Time of day to
start regenera-
tion
1:00 - 12:59
AM or PM
00:00 - 23:59
As required Hour
Minute
Range depends on value selected for
P13 Use only if P15 = 0 or 1
P3 Factory 10
P4 Does not apply 0.5
0.2
P5 Factory 10
U.S.- Divide the volumetric capacity
(gallons) of the filter by 100 and enter
this number into P5
Metric - Divide the volumetric
capacity (cubic meters) by 10 and
enter this number into P5
P6 Refill controller 2 - 200 1 200 Do not change
P7 Brine draw rate 2 - 200 1 200 Do not change
P9 Backwash time 7 - 60 1 14 Minutes May be adjusted for application
P10 Does not apply 7 - 125 1 8 Minutes May be adjusted for application
P11 Fast Rinse 9 - 60 1 9 Minutes May be adjusted for application
P12 Units of
measure
0 - 1 1 0 0 = US, 1 = Metric
P13 Clock mode 0 - 1 1 0 0 = 12 hour clock, 1 = 24 hour clock
P14 Interval
Regeneration
0 - 30 1 0 Days
between
regeneration
0 = No Interval chosen - *May be
adjusted for application
P15 Does not apply
for Timeclock
operation
0
P16 Does not apply
for Timeclock
operation
30
P17 Operation type 7 7 = Filter TimeClock
P18 Salt Change
Lock Out
0 - 1 1 0 0 = none 1 = Salt /Capacity Change
Locked Out
P19 Does not apply
for Timeclock
operation
P20 Does not apply
for Timeclock
operation
P21 Remote
Regeneration
Switch Delay
1 - 254 1 60 Seconds Time remote switch must be active to
start regeneration.
P22 Factory Use
Only – DO NOT
CHANGE
99
Do not change
