Autotrol Magnum Cv 942F User Manual

75
12.8 Installation Adapters
Adapters- Magnum
Adapters-Magnum IT
Item Part Number Description
Not Shown 1001657 Magnum Cv 1.5-inch Adapter Kit - Brass NPT for inlet, outlet, drain
Not Shown 1001658 Magnum Cv 1.5-inch Adapter Kit - Brass BSP for inlet, outlet, drain
1 1001655 Magnum Cv 1.5-inch Adapter Kit - CPVC for inlet, outlet, drain
Not Shown 1040544 1.5-inch NPT Brass Adapter with Glass Filled Noryl Nut (24 Pack)
Not Shown 1040555 1.5-inch BSP Brass Adapter with Glass Filled Noryl Nut (24 Pack)
1 1050556 1.5-inch CPVC Adapter with Glass Filled Noryl Nut (24 Pack)
2 1000356 Glass Filled Noryl Nut for 1.5-inch Adapter
Not Shown 1000360 1.5-inch Brass NPT Adapter
Not Shown 1000361 1.5-inch Brass BSP Adapter
3 1000356 1.5-inch CPVC Adapter
Not Shown 1001995 1-1/2-inch Brass NPT Adapter with Drilled and Tapped 1/4-inch NPT Port
Not Shown 1001996 1-1/2-inch Brass BSP Adapter with Drilled and Tapped 1/4-inch BSP Port
Item Part Number Description
Not Shown 1040782 Magnum IT Adapter Kit - Brass NPT for inlet, outlet, drain
Not Shown 1040783 Magnum IT Adapter Kit - Brass BSP for inlet, outlet, drain
Not Shown 1040784 Magnum IT Adapter Kit - CPVC for inlet, outlet, drain
Not Shown 1040786 2-inch NPT Brass Adapter with Zinc Diecast Nut (24 Pack)
Not Shown 1040787 2-inch BSP Brass Adapter with Zinc Diecast Nut (24 Pack)
Not Shown 1040788 2-inch CPVC Adapter with Zinc Diecast Nut (24 Pack)
Not Shown 1030664 2-inch Cast Zinc Diecast Nut
Not Shown 1030663 2-inch Brass NPT Adapter
Not Shown 1033863 2-inch Brass NPT Adapter with Drilled and Tapped 1/4-inch NPT Port
