Autotrol Magnum Cv 942F User Manual

39
6.6 Table IIE
Level II Program Values - Electronic Timeclock Softener (P17=1)
Parameter Description Range of Values
Min.
Increment
Factory Value
Units of
Measure
Notes
P1 Day of Week and
Time of day
(1-7) 1:00 - 12:59
AM or PM
Metric
(1-7) 0:00 - 23:59
(1 day)
1 minute
Current Day and Time Hour
Minute
Range depends on value selected
for P13
For day of week SUN=1, MON=2,
TUE=3, WED=4, THU=5, FRI=6,
SAT=7. THIS IS THE LEFT
MOST DIGIT ON THE DISPLAY
P2 Time of day to start
regeneration
1:00 - 12:59
AM or PM
00:00 - 23:59
As required Hour
Minute
Range depends on value selected
for P13 Use only if P15 = 0 or 1
P3 Hardness 10
P4 Salt Amount 5 – 1250
2 - 500
5
2
As required Unit of Measure depends on
selection in P12
P5 Does not apply for
TimeClock operation
10
P6 Refill controller 2 - 200 1 0 Selected from chart in
Performance Data Sections,
page 57
P7 Brine draw rate 2 - 200 1 0 Selected from chart in
Performance Data Sections,
page 58
P9 Backwash time 4 - 60 1 14* Minutes *May be adjusted for application
P10 Rinse time 7 - 125 1 40* Minutes *May be adjusted for application
P11 Fast Rinse 2 - 60 1 4* Minutes *May be adjusted for application
P12 Units of measure 0 - 1 1 0 0 = US, 1 = Metric
P13 Clock mode 0 - 1 1 0 0 = 12 hour clock, 1 = 24 hour
clock
P14 Interval
Regeneration
0 - 30 1 0 Days
between
regeneration
0 = No Interval chosen - *May be
adjusted for application
P15 Does not apply for
Timeclock operation
P16 Does not apply for
Timeclock operation
P17 Operation type 1 1 = Magnum Cv Softener
TimeClock
P18 Salt Change Lock
Out
0 - 1 1 0 0 = None 1 = Salt /Capacity
Change Locked Out
P19 Does not apply for
TimeClock operation
P20 Does not apply for
TimeClock operation
P21 Remote
Regeneration
Switch Delay
1 - 254 1 60 Seconds Time remote switch must be
active to start regeneration.
P22 Factory Use Only –
DO NOT CHANGE
99
Do not change
