6.2 Table IIA
Level II Program Values - 962 Single Twin or Triple Parallel Tank Softener or Dealkalizer (P17=0)
Note: This programming sheet is for use with controls
manufactured after 09 Aug 2000.
Parameter
Description of
Program Values
Range of Values
Min.
Increment
Factory
Value
Units of Measure Notes
P1 Day of Week and
Time of day
(1-7) 1:00 - 12:59
AM or PM
Metric (1-7)
0:00 - 23:59
(1 day)
1 minute
None Hour
Minute
Range depends on value selected for
P13. For day of week SUN=1, MON=2,
TUE=3, WED=4, THU=5, FRI=6, SAT=7.
This is the left most digit on the display.
P2 Time of day to start
regeneration
1:00 - 12:59
AM or PM
00:00 - 23:59
1 None Hour
Minute
Range depends on value selected for
P13 Use only if P15 = 0 or 1
P3 Hardness of water 3-250
30-2500
1
10
0
0
Grains per gallon
ppm
Unit of measure depends on value
selected for P12
P4 Salt amount 5 – 1250
2 - 500
5
2
10
4
Pounds
Kilograms
Unit of measure and factory value
depends on value selected for P12
P5 Capacity of unit 1-2600
0.1-260.0
1
0.1
0
0
Kilograins
Kilograms
Unit of measure depends on value
selected for P12
P6 Refill controller 2 - 99 1 0 Selected from chart in Performance Data
Sections, page 57
P7 Brine draw rate 2 - 99 1 0 Selected from chart in Performance Data
Sections, page 58
P9 Backwash time 4 - 30 1 14 Minutes May be adjusted for application
P10 Rinse time 7 - 125 1 40 Minutes May be adjusted for application
P11 Purge time 2 - 19 1 4 Minutes May be adjusted for application
P12 Units of measure 0 - 1 1 0 0 = US, 1 = Metric
P13 Clock mode 0 - 1 1 0 0 = 12 hour clock, 1 = 24 hour clock
P14 Calendar override 0 - 30 1 0 Days 0 = no calendar override
P15 Reserve Type 0 - 3 1 0 0=Variable Reserve, 1=Fixed Reserve
2=Variable Reserve with immediate
regeneration , 3=Fixed Reserve with
immediate regeneration
P16 Initial average
usage or fixed
reserve
0 - 70 1 30 Percent of Total
capacity
P17 Operation type 0 - 2 1 0 0 = Single or Parallel
P18 Salt/Capacity
Change Lock Out
0 - 1 1 0 0 = none, 1 = Salt /Capacity Change
Locked Out
P19 Flow Sensor select 0 0 = Magnum IT NHWB, 1 = 1.0" Autotrol
turbine, 2 = 2.0” Autotrol turbine, 3 =
User defined K-factor, 4 = User defined
pulse equivalent, 5 = Magnum IT HWB
P20 K-factor or Pulse
equivalent
0.01 - 255.00 .01 0.01 Number used for Meter K-factor or Pulse
equivalent
P21 Remote
Regeneration
Switch Delay
1 - 254 1 60 Seconds Time remote switch must be active to
start a regeneration.
P22 Factory Use Only
– DO NOT
CHANGE
99
Do not change
