Autotrol Magnum Cv 942F User Manual

36
6.3 Table IIB
Level II Program Values - 962F Single Tank Filter (P17=4)
Parameter
Description of
Parameter
Range of Values
Min.
Increment Factory Value Units of Measure Notes
P1 Day of Week and
Time of day
1:00 - 12:59
AM or PM
0:00 - 23:59
1 None Day
Hour:Minute
Range depends on value selected for
P13. For day of week SUN=1, MON=2,
TUE=3, WED=4, THU=5, FRI=6,
SAT=7. This is the left most digit on the
display.
P2 Time of day to start
regeneration
1:00 - 12:59 AM or PM
00:00 - 23:59
1 2:00 AM Hour:Minute Range depends on value selected for
P13. Use only if P15 =1
P3 Factory 10
100
Grains per gallon
ppm
Unit of measure depends on value
selected for P12
P4 Salt amount 0.5 – 125.0
0.2 - 50.0
0.5
0.2
0.5
0.2
Pounds
Kilograms
Unit of measure and factory value
depend on value selected for P12
P5 0 U.S. - Divide the volumetric capacity
(gallons) of the filter by 100 and enter
this number into P5.
Metric - Divide the volumetric capacity
(cubic meters) by 10 and enter this
number into P5.
P6 Refill controller 2 - 200 1 200
gpm x 100
Do not change.
P7 Brine draw rate 2 - 200 1 200
gpm x 100
Do not change.
P9 Backwash time 7 - 60 1 14 Minutes May be adjusted for application.
P10 Does not apply 7 - 125 1 8 Minutes
Do not change
P11 Purge time 9 - 60 1 9 Minutes
May be adjusted for application.
P12 Units of measure 0 - 1 1 0 0 = US, 1 = Metric
P13 Clock mode 0 - 1 1 0 0 = 12 hour clock, 1 = 24 hour clock
P14 Calendar override 0 - 30 1 0 Days 0 = no calendar override
P15 Reserve Type 0 - 3 1 0 0 = variable reserve 1 = fixed reserve,
2 = variable reserve with immediate
regen, 3 = fixed reserve with immediate
regen.
P16 Initial average
usage or fixed
reserve
0 - 70 1 30 Percent of Total
capacity
Description depends on value entered
for P15.
P17 Operation type 0 - 7 4 0 4 = filter
P18 Salt/Capacity
Change Lock Out
0 - 1 1 0 0 = none 1 = Salt /Capacity Change
Locked Out
P19 Flow Sensor select 1 - 4 1 0 0 = Magnum IT NHWB
1 = 1.0" Autotrol Turbine
2 = 2.0” Autotrol Turbine
3 = User defined K-factor
4 = User defined pulse equivalent
5 = Magnum IT HWB
P20 K-factor or Pulse
equivalent
0.01 -255.00 0.01 0.01 Number used for Meter K-factor or
Pulse equivalent
P21 Remote
Regeneration
Switch Delay
1 - 254 1 60 Seconds Time remote switch must be active to
start a regeneration.
P22 Factory Use Only 0 - 9 1 99 Do not change.
