Autotrol Magnum Cv 942F User Manual

22
Minimum salting: 6 lb. salt = 20 kgr/cu. ft.
Medium salting: 10 lb. salt = 25 kgr/cu. ft.
Maximum salting: 15 lb. salt = 30 kgr/cu. ft.
Table 5.4 Suggested Brine Draw/Slow Rinse Times Based on 75 psi and 2.5 Bed Volumes of
Slow Rinse
Tank Size in. (cm) 14 (35.5) 16 (40.6) 18 (45.7) 21 (53.3) 24 (60.9) 30 (76.2) 36 (91.4)
Resin Vol. cu. ft. (cu m) 3 (0.085) 4 (0.113) 5 (0.142) 7 (0.200) 10 (0.283) 15 (0.425) 20 (0.566)
Brine/ Rinse Time 55 min 52 min 61 min 57 min 58 min 66 min 55 min
Total Lb. Salt [Min.] (kg) 18 (6.72) 24 (8.96) 30 (11.2) 42 (15.68) 60 (22.39) 90 33.59)
120
(44.79)
Capacity (kgr) 60 80 100 140 200 300 400
Brine/Rinse Time 64 min 64 min 73 min 70 min 69 min 76 min 64 min
Total Lb. Salt [Mid] (kg) 30 (11.2) 40 (14.93) 50 (18.66) 70 (21.13)
100
(37.32)
150
(55.99)
200
(74.65)
Capacity (kgr) 75 100 125 175 250 375 500
Brine/Rinse Time 75 min 79 min 88 min 85 min 82 min 90 min 75 min
Total Lb. Salt [Max] 45 (16.8) 60 (22.39) 75 (27.99) 105 (39.19
150
(55.99)
225
(83.98)
300
(111.97)
Capacity (kgr) 90 120 150 210 300 450 600
Injector Number 1000441 1000442 1000443 1000444 1000445 1000446 1000447
Table 5.5 Suggested Brine Draw/Slow Rinse Times Based on 100 psi and 2.5 Bed Volumes of
Slow Rinse
Tank Size in. (cm) 14 (35.5) 16 (40.6) 18 (45.7) 21 (53.3) 24 (60.9) 30 (76.2) 36 (91.4)
Resin Vol. cu. ft. (cu m) 3 (0.085) 4 (0.113) 5 (0.142) 7 (0.200) 10 (0.283) 15 (0.425) 20 (0.566)
Brine/ Rinse Time 50 min 48 min 56 min 53 min 54 min 59 min 50 min
Total Lb. Salt [Min.] (kg) 18 (6.72) 24 (8.96) 30 (11.2) 42 (15.68) 60 (22.39) 90 33.59)
120
(44.79)
Capacity (kgr) 60 80 100 140 200 300 400
Brine/Rinse Time 59 min 60 min 68 min 65 min 64 min 69 min 59 min
Total Lb. Salt [Mid] (kg) 30 (11.2) 40 (14.93) 50 (18.66) 70 (21.13)
100
(37.32)
150
(55.99)
200
(74.65)
Capacity (kgr) 75 100 125 175 250 375 500
Brine/Rinse Time 70 min 75 min 83 min 81 min 77 min 82 min 70 min
Total Lb. Salt [Max] 45 (16.8) 60 (22.39) 75 (27.99) 105 (39.19
150
(55.99)
225
(83.98)
300
(111.97)
Capacity (kgr) 90 120 150 210 300 450 600
Injector Number 1000441 1000442 1000443 1000444 1000445 1000446 1000447
