Figure 12.12 Magnum 962TC
Figure 12.13 Magnum 962FTC
* Battery Not Included.
* Battery Not Included.
TC
Magnum 962TC
TIME OF BACKWASH
SET VALUE TO 10
SET VALUE TO 5
CAPACITY
REMAINING
SET
BACKWASH
BACKWASH
FLOW PM
COMPLETE
BACKWASH TIME
TIME OF DAY
B
A
C
K
W
A
S
H
P
U
R
G
E
TM
Magnum Cv 962FTC
Magnum 962FTC
Table 12.7 962 Electronic Control 12V/50 Hz Configurations
Part Number Description
1046860 Electronic Control/962 Softener/Battery Backup/12 VAC/50 Hz*
1046862 Electronic Control/962M Main/Battery Backup/12 VAC/50 Hz*
1046863 Electronic Control/962S Secondary/12 VAC/50 Hz
1046873 Electronic Control/962F Filter/Battery Backup/12 VAC/50 Hz*
Table 12.8 962 Electronic Control 12 V/ 60 Hz Configurations
Part Number Description
1046327 Electronic Control/962 Softener/Battery Backup/12 VAC/60 Hz*
1046329 Electronic Control/962M Main/Battery Backup/12 VAC/60 Hz*
1046330 Electronic Control/962S Secondary/12 VAC/60 Hz
1046867 Electronic Control/962F Filter/Battery Backup/12 VAC/60 Hz*
1053846
Electronic Time Clock Control/962TC Softener/Battery Backup/12 VAC/60
Hz
1053847 Electronic Time Clock Control/962FTC Filter/Battery Backup/12 VAC/60 Hz
