Autotrol Magnum Cv 942F User Manual

79
* For use with 962M and 962S controls only.
10 1000467 Pilot Cam - Co-current 5 Cycle Softener #4 (Yellow)
11 1000468 Pilot Cam - Co-current 5 Cycle Softener #5 (Orange)
12 1000469 Pilot Cam - Co-current 5 Cycle Softener #6 (Red)
13 1000460 Spacer Cam - 3 Cycle Filter (Grey)
14 1000462 Universal Cam Switcher (Black)
15 1000470 Pilot Cam - 3 Cycle Filter #1 (Grey)
16 1000471 Pilot Cam - 3 Cycle Filter #2 (Blue)
17 1000472 Pilot Cam - 3 Cycle Filter #3 (Green)
18 1000473 Pilot Cam - 3 Cycle Filter #4 (Yellow)
19 1000474 Pilot Cam - 3 Cycle Filter #5 (Orange)
20 1000469 Pilot Cam - 3 Cycle Filter #6 (Red)
21 1000499 Brine Cam - Twin Alternating (Tan)
22 1001750 Universal Cam Switcher (Tan)
23 1001620 Pilot Cam - Twin Alternating #1 (Tan)
24 1001621 Pilot Cam - Twin Alternating #2 (Blue)
25 1001622 Pilot Cam - Twin Alternating #3 (Green)
26 1001623 Pilot Cam - Twin Alternating #4 (Yellow)
27 1001624 Pilot Cam - Twin Alternating #5 (Orange)
28 1000469 Pilot Cam - Twin Alternating #6 (Red)
29 1000589 Pillow Block Cap
Not Shown 1006095 Pillow Block Cap Screw (4) (not shown)
31 1000339 Top Plate
Not Shown 1006093 Top Plate Screw - Short (5) (not shown)
Not Shown 1006095 Top Plate Screw - Long (9) (not shown)
34 1000391 Brine Flapper Valve
35 1000328 Pilot Flapper Valve
Not Shown 1000553 Cam for Auxiliary output, shuts off at end of refill
Not Shown 1000554 Cam for Auxiliary output, shuts off at beginning of refill
Not Shown 1001580 Flapper Return Spring
Not Shown 1000343 Cam Cover
Item Part Number Description

Autotrol Magnum Cv 942F Specifications

General

Brand	Autotrol
Model	Magnum Cv 942F
Category	Control Unit
Language	English
