19
400 Series Technical specification
Technical specification
*) Load is measured at 400 mm from the attachment coupling plate, including attachment weight ( 70 kg ) and with counterweights.
Model AVANT 423
Length 2195 mm
Width see table
Height 1980 mm
Weight 1080 kg
Standard wheels 23x8.50-12”grass/TR
Transmission, drive hydrostatic
Pulling force 700 kp
Drive speed 12 km/h
Hydraulic oil tank capacity 26 l
Hydraulic oil type ISO VG 46
Auxiliary hydraulics oil ow / pressure 34 l/min 185 bar
Turning radius inside/outside 880 / 1970 mm
Max. lifting height 2750 mm
Max. lifting capacity (hydr.) 690 kg
Max. tipping load* 550 kg
Max. breakout force / 50 cm 650 kg
Sound pressure level 2000/14/EC L
P
81 dB (A)
Sound power level 2000/14/EC L
W
96 dB (A)
Hand-arm vibration, total
< 2,5 m/s²
Whole-body vibration, max. < 0,5 m/s²
2195 mm
710 mm 1100 mm
385 mm
2750 mm
2265 mm
1980 mm
200 mm
600 mm
990 -1095 mm
1980 mm
