CHAPTER 6
Instructions, use and maintenance manual
Page 52
Drago PZero
6.2.2. LOW FLAME ADJUSTMENT
IMPORTANT!
All burners are adjusted by our technicians before being shipped.
To change the factory settings, carry out the procedure described below.
For the low ame adjustment procedure, carry out the operations described below:
STEP ACTION PICTURE
1 Press and rotate the selection knob anti-clockwise.
2 Set the selection knob on the “LOW FLAME” symbol.
3
Extract the knob “A” by grasping it with your ngers and
pulling it rmly outwards.
A
4
Adjust the height of the high ame by actuating the screw
“C”.
The ow rate is correct when the ame touches the cupola
and the empty oven does not increase in degrees.
C
