AC Power and Ground
Issue 10 June 2005 45
CMC Power Switch
CAUTION:
CAUTION: The latch only removes DC power from the cabinet. Unseating the power supply
removes AC power from the power supply, but not from the cabinet. To remove
AC power from the cabinet, pull the AC power cord from the AC appliance
connector on the rear of the cabinet. See Figure 9
.
Figure 9: CMC Power Supply
Figure notes:
1. Latch
psdmdc RPY 01199
1
