Avaya CMC1 - Vertically and Horizontally Mounted System

Installing and Cabling the Cabinets
52 Installation, Upgrades and Additions for Avaya CMC1 Media Gateways
Vertically and Horizontally Mounted System
Only 1 horizontal TDM/LAN Bus cable is allowed per system. See Figure 15.
1. Route the TDM/LAN bus cables through the cable trough.
Figure 15: System Cable Connections
Figure notes:
1. TDM/LAN bus terminator (at each
end of the TDM/LAN bus)
2. Vertical TDM/LAN bus cable (List 8)
3. Horizontal TDM/LAN bus
cable (List 9)
indmin10 KLC 082002
B
A
C
1
TOP
1
1
3
2
