Avenir 4/8CH DVR - Technical Specifications; Key Specifications Summary

13
2. Select proper TIME ZONE time.
NOTE: If you want the unit to automatically synchronize the local time, the Time Zone must be
properly set according to your local Time Zone.
Specification
ITEM 4ch 8ch 16ch
Video
Input
Channel,
Input Level
4/8/16CH HD-SDI (1080p25/30, 1080i50/60, 720p25/30/50/60
Auto Detection)
Output
HDMI 1 HDMI (Max 1920x1080p60 and Various Resolution)
VGA 1 VGA (Max 1920x1080p60 and Various Resolution)
Audio
Input 4/8/16CH RCA
Output 1 RCA, 1 HDMI
Audio Codec G.711
Alarm
Sensor Input 4/8/16ch (NC/NO Selectable)
Alarm Output 1/2/4ch Alarm out by Sensor, Motion and Video Loss
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Resolution
NTSC/PAL
1080p 20fps 40fps 80fps
720p 48fps 96fps 192fps
640x360 60fps 120fps 240fps
Recording quality grade LEVEL 1 (Low), 2, 3, 4, 5 (High)
Recording Mode Continuous / Schedule / Motion/ Sensor/ Manual
Pre & Post Recording Yes
Display Frame Rate ( /Sec) NTSC: 30fps/ch, 60 fields / PAL: 25fps/ch, 50 fields
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 8, 16
Playback
Speed
Single
channel
x 1/4, 1/2, 1, 2, 4, 8, 16, 32, 64
