88
o Site Name: Input a name that properly describes a site.
o IP Address: Input IP address (Public IP address of a router that DVR is connected.) or Domain
name that is registered at www.okddns.com (for Korea), www.ddnscenter.com (for USA) or
www.bestddns.com (for other area including EU)
o Port No.: Input port number of DVR.
o ID: Input ID of DVR.
o Password: Input network password of DVR.
2. Click OK button. And then the registered site is added on the directory window.
9-8-1-2. Delete of sites
1. Select the site/sites to delete from the directory window.
2. Click SITE DELETE button. And then the selected site/sites is/are deleted.
9-8-1-3. Modify of sites
1. Select the site/sites to modify from the directory window.
