Scope of delivery
AVENTICS | ECS Actuator | R417002911–BDL–001–AA 13
English
4 Scope of delivery
The standard product delivery includes:
W 1 Marex ECS Actuator 12V DC (R417002894) or
1 Marex ECS Actuator 24V DC (R417002895)
W Assembly instructions
W 1 Mounting kit including the following items:
1 Ball joint
1Clamp
2 Cheese-head screws M5x12 (wrench size 4)
1 Cheese-head screw M6x16 (wrench size 5)
1Washer Ø 6.4mm
1 Spring washer Ø 6.4mm
3 Hexagon screws M8x45 (wrench size13)
3 Washers Ø 8.4
3 Hexagon nuts M8 (wrench size 13)
