Commissioning
30 AVENTICS | ECS Actuator | R417002911–BDL–001–AA
8 Commissioning
The Marex ECS Actuator is designed to be used with the
Marex ECS engine remote control system. All system
components must be registered, configured and tested before
the first operation. Marex ECS features auto-configuration
(auto-config) to facilitate this process. However, the actuator’s
function must be set before starting the Marex ECS autoconfig.
Make sure to set the actuator’s function before starting the
Marex ECS auto-config (see 8.1, step 5).
8.1 Switches and LEDs
The actuator provides three switches and two LEDs for the
settings and operational status indication. These are located on
the actuator under a transparent cover.
