Aventics Marex ECS User Manual

Technical data
AVENTICS | ECS Actuator | R417002911–BDL–001–AA 49
English
13 Technical data
Table 14: Technical data
Dimensions
width x height x depth 146 mm x 306.5 mm x 134 mm
Weight 3kg approximately
Supply voltage 12VDC (-25%/+30%) (R417002102)or
24VDC (-25%/+30%) (R417002103)
Typical current consumption 6 A (12 V)
3A (24V)
Maximum current consumption 12A (12V)
6 A (24V)
Rated stroke 76mm (3 inch)
Rated force 150N
Temporary force max. 180N
Admissible ambient temperature 248 to 350K (-25° C to +77° C)
Admissible storage temperature 233K to 358K (-40°C to +85°C)
Protection class IP 65 - EN 60529 (IEC 60529)
Vibration resistance IEC 60068-2-6
Range 2-13 Hz: ± 1.6mm
Range 13-100 Hz: ± 4g
Shock resistance 10g / 11ms
Rel. humidity 5% - 98% incl. condensation
Material Aluminum, anodized

Aventics Marex ECS Specifications

General

Brand	Aventics
Model	Marex ECS
Category	Control Unit
Language	English
