Assembly
AVENTICS | ECS Actuator | R417002911–BDL–001–AA 27
English
Consider the admissible length of the PROPULSION cables when
connecting Marex ECS Actuators. The maximum length of all
PROPULSION cables is 250m.
7. Attach a terminating resistor to sockets (6, fig. 8) which are
not used. Both sockets (6, fig. 8) must be occupied on all
Marex ECS Actuators.
The terminating resistor is not included in the delivery. It must
be ordered separately. Refer to chapter 14 for details on the
terminating resistor.
7.2.3 Connecting the power supply
You can connect the MarexECS Actuator either to one or two
batteries (dual battery operation). Different cables are available
for every option (see chapter 18). Connecting a second battery is
a safety measure by means of which the power supply can be
switched over to a second battery if the first one is too low to
operate the actuator. The dual battery power cable is equipped
NOTICE
Material damage due to unapplied terminating resistor
If the terminating resistor is not applied, the data
transmission can be disturbed. Then the boat’s speed can no
longer be controlled.
O Make sure that all required terminating resistors are
correctly applied.
